1991 Mazda Mx5 NA (For Sale)

Vehicle Details

Vehicle
1991 Mazda Mx5 NA
Build Year
1991
Price
$35,000
Kilometres
153998 KM
Colour
Blue
Transmission
Manual
Engine Capacity
1.6L
Reg Plate
BU8813
Reg Expiry
15 June 2026
Description

After 25 years I have decided to sell my pride and joy. This is no ordinary MX5. It needs to go to an owner who can appreciate it as much as I have. I have had my fun but I don't drive it very often so I have decided to sell. Well over $100k has been spent and its all top end components. List of all the mods are attached.

Mariner Blue Mazda MX5 1991 NA (Bubble) List of Modifications. Road registered in NSW. Rego BU8813. 153998 Genuine Klms. Rego Expiry 15th June 2026.

Engine:

Reliable 260 KW ATW running between 23-25 lbs of boost. 400HP at the flywheel. Less than 5000klms on a new 1.6 litre. As per original, although B6 block is from a much later model.

Fully Built by KC’s Engine Balancing and Head Service Castle Hill.

Long nose Crank.

Garrett GTX2860R turbo T25 Inlet, with 0.86AR Exhaust Housing.

Turbosmart Boost Control and Blow Off Valve.

AVO Cast Exhaust Manifold.

Inconel Fasteners all wired.

Full custom 3” Exhaust system and Dump Pipe.

Manley Sport Compact H Beam Rods.

Wiseco Forged Pistons.

ACL Race Main and Rod Bearings.

ARP Head and Rod Bolts.

Cometic Head Gasket.

Ported Head with Supertech Oversized Valves, dual Valve Springs with Titanium Retainers.

Solid Lifters.

Kelford 272/272 Degree Camshafts.

ATI Harmonic Damper.

Skunk 2 Pro 64mm Billet Throttle Body with ported factory Intake Manifold.

Boundary Engineering Billet Geared Oil Pump.

AWR Engine Mounts.

Brisk Silver DR14YS Spark Plugs.

Fuel System

Injector Dynamics 1000cc Injectors.

Deutz Fuel Pump.

Runs on E85 with flex fuel sensor.

Radium Fuel Rail.

Upgraded Lines and Fuel Filter.

Turbosmart Fuel Pressure Regulator.









ECU and Electronics.

Adaptronic ECU.

Haltech IC7 Dash and Dash Enclosure.

4 BAR Map Sensor.

Toyota Coil on Plug setup.



Cooling

40mm Aluminium Radiator.

Davies Craig electric water pump.

Twin SPAL Thermo Fans

Dual Thermostats with Coolant Reroute setup.

AVO Intercooler.

Prospeed Oil Cooler with thermostat and braided lines.

Brakes

Front brakes Yellowspeed 6 piston calipers with 304mm 2 piece Rotors

Rear brakes 2004 SE MX5 Calipers and Rotors.

Hawk Blue Brake Pads.

Willwood dual channel adjustable Brake system.

Penrite racing fluid.

Braided brake and clutch lines.

Wheels and Tyres

Wheels are Enkei RPF1 16x8 4x100 +38mm offset.

Tyres Advan AD08R currently fitted.

Also a set of Hankook Slicks with only 2 heat cycles.

Flyin Miata Blue Printed Front Hubs.

Chassis and Suspension

For the road I have shockworx Coilovers with less than 300klms on them. Currently fitted.

For the track I have Yellowspeed premium racing coilovers.

Cusco Anti Sway Bars.

Adjustable Sway bar end links.

Strong Arm Front Horn Braces.

Whiteline Front Strut Brace.

Jass performance Chassis rail reinforcement.

Racing Beat Front lower control arm brace.

Rear Subframe reinforcement.

Superpro Polyurethane Bushes on Control Arms, sway bars and Diff.

Depowered Steering Rack, with tie rod end links to suit lowered suspension.



Gearbox and Differential.

Brand new MX5 6 speed from SE imported from Japan. Immediately upgraded. All gears double clipped and gearset Cryogenically hardened. Done by Adam at Hornsby Gearboxes and Diffs. Done less than 200klms.

CAE Ultra Shifter for 6 speed.

Flyin Miata Stage 3 Organic Clutch. Rated for 500HP. Flyin Miata Lightweight Flywheel.

OS Giken Super Lock LSD set up by Adam at Hornsby Gearboxes and Diffs.

1.8L Diff Housing, prop shaft and axles.

Interior

Stainless half cage

2 x Sparco R100 Seats.

1 x EVO Racing Seat for the track

6 point harness.

Stainless door sills.

Exterior

Carbon Fibre Hardtop with all factory rubber seals and Polycarbonate rear window.

Carbon Miata GV style front Lip.

Aluminium Front Splitter

Carbon Miata Rear Boot Lip.

Carbon Miata Front Cuards.

Aftermarket Mohair Softtop and factory cover.





Miscellaneous

Prospeed Vacuum Hose manifold.

Toshiba Laptop Loaded with Adaptronic Maps and IC7 Software





Notes

Owned the Car since 2001. Never a daily, always a project car.

Done probably 10 Track Days in that time.

MX5 mania and Hornsby Diffs and Gearboxes done specialist work and tuning.

Won Best in Show at recent Cars and Stars at MX5 Mania.



Owner: Craig Gartlacher

Mobile: 0410284180.

Email: cgartlacher@hotmail.com
